नेविगेशन यूज़र इंटरफ़ेस (यूआई) में बदलाव करना

< > नेविगेशन गतिविधि के लिए Java कोड दिखाएं/छिपाएं.

package com.example.navsdkcustomization;

import android.content.pm.PackageManager;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.support.v4.app.ActivityCompat;
import android.support.v4.content.ContextCompat;
import android.support.v7.app.AppCompatActivity;
import android.util.Log;
import android.widget.Toast;
import androidx.annotation.NonNull;
import com.google.android.libraries.navigation.Camera;
import com.google.android.libraries.navigation.LatLng;
import com.google.android.libraries.navigation.ListenableResultFuture;
import com.google.android.libraries.navigation.Marker;
import com.google.android.libraries.navigation.MarkerOptions;
import com.google.android.libraries.navigation.NavigationApi;
import com.google.android.libraries.navigation.NavigationMap;
import com.google.android.libraries.navigation.Navigator;
import com.google.android.libraries.navigation.SimulationOptions;
import com.google.android.libraries.navigation.StylingOptions;
import com.google.android.libraries.navigation.SupportNavigationFragment;
import com.google.android.libraries.navigation.Waypoint;

/**
 * An activity that displays a map and a customized navigation UI.
 */
public class NavigationActivityCustomization extends AppCompatActivity {

    private static final String TAG = NavigationActivityCustomization.class.getSimpleName();
    private Navigator mNavigator;
    private SupportNavigationFragment mNavFragment;
    private NavigationMap mMap;
    // Define the Sydney Opera House by specifying its place ID.
    private static final String SYDNEY_OPERA_HOUSE = "ChIJ3S-JXmauEmsRUcIaWtf4MzE";
    // Set fields for requesting location permission.
    private static final int PERMISSIONS_REQUEST_ACCESS_FINE_LOCATION = 1;
    private boolean mLocationPermissionGranted;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Initialize the Navigation SDK.
        initializeNavigationSdk();
    }

    /**
     * Starts the Navigation SDK and sets the camera to follow the device's location.
     * Calls the navigateToPlace() method when the navigator is ready.
     */
    private void initializeNavigationSdk() {
        /*
         * Request location permission, so that we can get the location of the
         * device. The result of the permission request is handled by a callback,
         * onRequestPermissionsResult.
         */
        if (ContextCompat.checkSelfPermission(this.getApplicationContext(),
                android.Manifest.permission.ACCESS_FINE_LOCATION)
                    == PackageManager.PERMISSION_GRANTED) {
            mLocationPermissionGranted = true;
        } else {
            ActivityCompat.requestPermissions(this,
                    new String[] { android.Manifest.permission.ACCESS_FINE_LOCATION },
                    PERMISSIONS_REQUEST_ACCESS_FINE_LOCATION);
        }

        if (!mLocationPermissionGranted) {
            displayMessage("Error loading Navigation SDK: "
                    + "The user has not granted location permission.");
            return;
        }

        // Get a navigator.
        NavigationApi.getNavigator(this, new NavigationApi.NavigatorListener() {
                    /**
                     * Sets up the navigation UI when the navigator is ready for use.
                     */
                    @Override
                    public void onNavigatorReady(Navigator navigator) {
                        displayMessage("Navigator ready.");
                        mNavigator = navigator;
                        mNavFragment = (SupportNavigationFragment) getFragmentManager()
                                .findFragmentById(R.id.navigation_fragment);

                        // Navigate to a place, specified by Place ID.
                        navigateToPlace(SYDNEY_OPERA_HOUSE);
                    }

                    /**
                     * Handles errors from the Navigation SDK.
                     * @param errorCode The error code returned by the navigator.
                     */
                    @Override
                    public void onError(@NavigationApi.ErrorCode int errorCode) {
                        switch (errorCode) {
                            case NavigationApi.ErrorCode.NOT_AUTHORIZED:
                                displayMessage("Error loading Navigation SDK: Your API key is "
                                        + "invalid or not authorized to use the Navigation SDK.");
                                break;
                            case NavigationApi.ErrorCode.TERMS_NOT_ACCEPTED:
                                displayMessage("Error loading Navigation SDK: User did not accept "
                                        + "the Navigation Terms of Use.");
                                break;
                            case NavigationApi.ErrorCode.NETWORK_ERROR:
                                displayMessage("Error loading Navigation SDK: Network error.");
                                break;
                            case NavigationApi.ErrorCode.LOCATION_PERMISSION_MISSING:
                                displayMessage("Error loading Navigation SDK: Location permission "
                                        + "is missing.");
                                break;
                            default:
                                displayMessage("Error loading Navigation SDK: " + errorCode);
                        }
                    }
                });
    }

    /**
     * Customizes the navigation UI and the map.
     */
    private void customizeNavigationUI() {
        // Set custom colors for the navigator.
        mNavFragment.setStylingOptions(new StylingOptions()
                .primaryDayModeThemeColor(0xff1A237E)
                .secondaryDayModeThemeColor(0xff3F51B5)
                .primaryNightModeThemeColor(0xff212121)
                .secondaryNightModeThemeColor(0xff424242)
                .headerLargeManeuverIconColor(0xffffff00)
                .headerSmallManeuverIconColor(0xffffa500)
                .headerNextStepTypefacePath("/system/fonts/NotoSerif-BoldItalic.ttf")
                .headerNextStepTextColor(0xff00ff00)
                .headerNextStepTextSize(20f)
                .headerDistanceTypefacePath("/system/fonts/NotoSerif-Italic.ttf")
                .headerDistanceValueTextColor(0xff00ff00)
                .headerDistanceUnitsTextColor(0xff0000ff)
                .headerDistanceValueTextSize(20f)
                .headerDistanceUnitsTextSize(18f)
                .headerInstructionsTypefacePath("/system/fonts/NotoSerif-BoldItalic.ttf")
                .headerInstructionsTextColor(0xffffff00)
                .headerInstructionsFirstRowTextSize(24f)
                .headerInstructionsSecondRowTextSize(20f)
                .headerGuidanceRecommendedLaneColor(0xffffa500));
        // Get the map.
        mMap = mNavFragment.getMap();
        // Turn off the traffic layer on the map.
        mMap.setTrafficEnabled(false);

        // Place a marker at the final destination.
        if (mNavigator.getCurrentRouteSegment() != null) {
            LatLng destinationLatLng = mNavigator.getCurrentRouteSegment()
                .getDestinationLatLng();

            Bitmap destinationMarkerIcon = BitmapFactory.decodeResource(
                    getResources(), R.drawable.ic_person_pin_48dp);

            mMap.addMarker(new MarkerOptions()
                    .position(destinationLatLng)
                    .icon(destinationMarkerIcon)
                    .title("Destination marker"));

            // Listen for a tap on the marker.
            mMap.setOnMarkerClickListener(new NavigationMap.OnMarkerClickListener() {
                @Override
                public void onMarkerClick(Marker marker) {
                    displayMessage("Marker tapped: "
                            + marker.getTitle() + ", at location "
                            + marker.getPosition().latitude + ", "
                            + marker.getPosition().longitude);
                }
            });
        }


        // Set the camera to follow the device location with 'TILTED' driving view.
        mNavFragment.getCamera().followMyLocation(Camera.Perspective.TILTED);
    }

    /**
     * Requests directions from the user's current location to a specific place (provided
     * by the Google Places API).
     */
    private void navigateToPlace(String placeId) {
        Waypoint destination;
        try {
            destination = Waypoint.fromPlaceId(placeId, null);
        } catch (Waypoint.UnsupportedPlaceIdException e) {
            displayMessage("Error starting navigation: Place ID is not supported.");
            return;
        }

        // Create a future to await the result of the asynchronous navigator task.
        ListenableResultFuture<Navigator.RouteStatus> pendingRoute =
                mNavigator.setDestination(destination);

        // Define the action to perform when the SDK has determined the route.
        pendingRoute.setOnResultListener(
                new ListenableResultFuture.OnResultListener<Navigator.RouteStatus>() {
                    @Override
                    public void onResult(Navigator.RouteStatus code) {
                        switch (code) {
                            case OK:
                                // Hide the toolbar to maximize the navigation UI.
                                if (getActionBar() != null) {
                                    getActionBar().hide();
                                }

                                // Customize the navigation UI.
                                customizeNavigationUI();

                                // Enable voice audio guidance (through the device speaker).
                                mNavigator.setAudioGuidance(
                                        Navigator.AudioGuidance.VOICE_ALERTS_AND_GUIDANCE);

                                // Simulate vehicle progress along the route for demo/debug builds.
                                if (BuildConfig.DEBUG) {
                                    mNavigator.getSimulator().simulateLocationsAlongExistingRoute(
                                            new SimulationOptions().speedMultiplier(5));
                                }

                                // Start turn-by-turn guidance along the current route.
                                mNavigator.startGuidance();
                                break;
                            // Handle error conditions returned by the navigator.
                            case NO_ROUTE_FOUND:
                                displayMessage("Error starting navigation: No route found.");
                                break;
                            case NETWORK_ERROR:
                                displayMessage("Error starting navigation: Network error.");
                                break;
                            case ROUTE_CANCELED:
                                displayMessage("Error starting navigation: Route canceled.");
                                break;
                            default:
                                displayMessage("Error starting navigation: "
                                        + String.valueOf(code));
                        }
                    }
                });
    }

    /**
     * Handles the result of the request for location permissions.
     */
    @Override
    public void onRequestPermissionsResult(int requestCode, @NonNull String permissions[],
                                           @NonNull int[] grantResults) {
        mLocationPermissionGranted = false;
        switch (requestCode) {
            case PERMISSIONS_REQUEST_ACCESS_FINE_LOCATION: {
                // If request is canceled, the result arrays are empty.
                if (grantResults.length > 0
                        && grantResults[0] == PackageManager.PERMISSION_GRANTED) {
                    mLocationPermissionGranted = true;
                }
            }
        }
    }

    /**
     * Shows a message on screen and in the log. Used when something goes wrong.
     * @param errorMessage The message to display.
     */
    private void displayMessage(String errorMessage) {
        Toast.makeText(this, errorMessage, Toast.LENGTH_LONG).show();
        Log.d(TAG, errorMessage);
    }
}
